Hikvision DS-7608NXI-K1/8P AcuSense NVR

Hikvision DS-7608NXI-K1/8P AcuSense NVR delivers advanced IP surveillance with deep learning-based AcuSense technology and 4K resolution support. This compact 1U device suits small to medium installations needing intelligent false alarm reduction, high-quality recording, and easy management.

Hikvision DS-7608NXI-K1/8P AcuSense NVR Use Cases

The Hikvision DS-7608NXI-K1/8P AcuSense NVR works well in various settings. Homeowners use it for monitoring larger properties and outbuildings. Small retail stores deploy it across sales floors, entrances, and storage areas. Offices install it to cover workspaces, receptions, and parking lots. Restaurants apply it to dining halls, kitchens, and exteriors.

Eight channels support comprehensive IP camera coverage. Users protect multiple zones effectively. Medium businesses benefit from smart features without complexity.

Built-in 8 PoE ports simplify deployment. Connect and power cameras directly. This reduces installation time and costs.

AcuSense filters alerts for humans and vehicles. Users focus on real threats only.

Hikvision DS-7608NXI-K1/8P AcuSense NVR Compatibility

The Hikvision DS-7608NXI-K1/8P AcuSense NVR supports Hikvision and third-party IP cameras via ONVIF. Cameras reach up to 8 MP resolution for detailed 4K footage.

Eight PoE ports follow IEEE 802.3af/at standards. Each powers cameras reliably.

Incoming bandwidth handles 80 Mbps. This supports multiple high-resolution streams.

Remote access uses the Hik-Connect app. Users view live and playback on smartphones seamlessly.

Plug-and-play setup detects cameras automatically. Configuration completes quickly.

Hikvision DS-7608NXI-K1/8P AcuSense NVR Key Advantages

AcuSense technology applies deep learning. It classifies humans and vehicles accurately. False alarms from animals, rain, or leaves drop by up to 90 percent.

Perimeter protection includes line crossing and intrusion detection. It targets relevant events only.

H.265+ compression reduces storage and bandwidth needs. Users record longer on single drives.

HDMI output supports 4K resolution. VGA provides Full HD simultaneously.

One SATA port accommodates up to 10 TB HDD. Extended archiving fits most needs.

Smart search highlights human or vehicle events. Review time shortens significantly.

Technical Specifications

Video and Audio

• IP Video Input: 8-ch, up to 8 MP resolution
• Video Compression: H.265+/H.265/H.264+/H.264/MPEG4
• Incoming Bandwidth: 80 Mbps
• Outgoing Bandwidth: 80 Mbps
• HDMI Output: 1-ch, 4K (3840 × 2160)/30Hz
• VGA Output: 1-ch, 1920 × 1080/60Hz
• Decoding Capability: 1-ch@8 MP (30 fps)/2-ch@4 MP (30 fps)/4-ch@1080p (30 fps)
• Synchronous Playback: 8-ch
• Two-Way Audio: 1-ch RCA

Network

• Network Interface: 1 × RJ45 10/100 Mbps self-adaptive
• PoE Interface: 8 × RJ45 10/100 Mbps, IEEE 802.3af/at
• PoE Power Budget: ≤ 120 W total
• Remote Connections: Up to 128 users
• Protocols: TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF

Storage

• SATA Interface: 1 × SATA
• Capacity: Up to 10 TB per HDD

Interface

• USB Interface: 1 × USB 2.0 (front), 1 × USB 3.0 (rear)
• Alarm In/Out: 4/1 (optional depending on region)

General

• Power Supply: 48 VDC, 1.5 A
• Consumption: ≤ 15 W (without HDD and PoE)
• Working Temperature: -10 °C to +55 °C
• Dimensions (W × D × H): 320 × 240 × 48 mm
• Weight: ≤ 1.5 kg (without HDD)

Trust and Support

Aiconic Computers offers genuine Hikvision products sourced from authorized channels. Each unit includes the full manufacturer warranty. Our Nairobi team provides professional installation guidance, configuration support, and reliable after-sales service. Fast delivery covers all Kenya regions. Visit our main website for complete service information.
